View the operator and parts manuals, and sell sheet for your Hybrid LT-Series light tower below.
Service Intervals and Recommended Parts
| Item Number | Item Description | Quantity |
| Lighting | ||
| 125900 | 350W DIMMABLE 48VDC LED LIGHT | 2 |
| Tower Components | ||
| 320185 | 3/16 x 10' STEEL TOWER CABLE | 2 |
| 100160 | 2 1/2 BALL BEARING PULLEY | 2 |
| 45040 | 3/16 CABLE THIMBLE | 2 |
| 620084 | 3/16 CABLE CLIP | 2 |
| Electrical | ||
| 123973 | UP/DOWN TOWER SWITCH | 1 |
| 123207 | ON/OFF CONTROL SWITCH | 1 |
| 122042 | PV500 CONTROLLER | 1 |
| 330499 | RECEPTACLE GFCI 20 AMP | 1 |
| 125157 | MEANWELL INVERTER 120VAC / 48VDC | 1 |
| Filters Kubota Z482 Variable Speed | ||
| *** | KUBOTA Z482 HYBRID FILTER KIT - AIR, OIL, & FUEL | 1 |
| 650290 | AIR FILTER | 1 |
| 118380 | OIL FILTER | 1 |
| 920745 | FUEL FILTER | 1 |
*** - Contact Allmand Parts & Service for more information.
Kubota Z482 Variable Speed Engine Service Intervals
| Air | Refer to Engine Op Manual |
| Oil | 250 Hours* |
| Fuel | 400 hours |
| Oil Capactiy | 4.0 U.S. qts (3.8 L) |
| Oil Type | 10W-30 (API CK-4) |
* - First Oil & Oil Filter Change - 50 hr
