Maxi-Power™ 45

Maxi-Power™ 45

Maximize the power and productivity of your job site with the NEW Maxi-Power™ 45 Mobile Generator. This generator comes equipped with a heavy-duty, oversized alternator equipped for starting any motor size needed. With a frequency switch for flexibility of job site power needs, and a tandem axle trailer for greater towing capabilities, this generator will last and deliver the power you need to get the job done.

For a tutorial video and more product support, visit the Maxi-Power™ operations page.

48.5

Standby Power (kVA)

45

Prime Power (kVA)

30+

Run Time (Hrs)

63

Sound Level (dBA)

Features

Fluid Containment System (FCS)

Holds 110% of all on-board fluids.

Oversized Electrical Lugs

Easy to connect leads (with no copper shaving).

Large Capacity Fuel Tank

Allows over 24 hour run time at full load.

EFPA (Electric Fuel Primer & Air-Bleed) Pump

No need to bleed air if fuel runs out.

Curbside Fluid Maintenance

Ease of serviceability.

Lockable Switch / Voltage Selector

Consistency on jobsite, keeping it where it was set by the operator on-site.

Voltage Single Phase – Switchable

120 V / 240 V

Voltage Three Phase – Switchable

120 V / 208 V or 277 V / 480 V

Standard Programmable Start / Stop for Standby Applications

Stand External Fuel Connections

Specifications

At least one product must be displayed. Please select another option to remove this product

Engine Brand
Isuzu
Engine Model
4LE2X
Engine Tier
Tier 4 Final
Output @ Rated Speed (1,800 RPM) - HP****
57.7
Standby Power - kVA (kW)
48.5 (39)
Prime Power - kVA (kW)***
45 (36)
Battery (V)
12
Voltage Regulation Percentage
0.50%
Amperage Single Phase 120 V (A)
108 x 2
Amperage Single Phase 240 V (A)
108
Amperage Three Phase 120 V / 208 V (A)
119
Amperage Three Phase 277 V / 480 V (A)
54
Excitation
Brushless with AVR
Armature Connection Layout
Star with Neutral/Zig/Zag
Insulation
Class H
Integral Fuel Tank Capacity (gal)
106
Runtime @ Full Load (hrs)
30+
Sound Level @ 23 ft. (No Load) - dBA
63
Engine Oil Change Interval (hrs)
500
Engine Fuel Filter Change Interval (hrs)
500
Dry Weight (lbs)
3,440
Operating Wet Weight (lbs)
4,100
Trailer GVWR (lbs)
4,900
Height With Towing Frame (in)
73
Length With Towing Frame (in)
142.5
Width With Towing Frame (in)
68
Number of Units on 48 Flatbed
4
Number of Units on 53 Flatbed
4

*Unit runs at full load for 24+ hours.
**See operator’s manual or www.allmand.com website for complete warranty details.
***Prime generator electrical output per Allmand® testing.
Pending Final Testing by Allmand.
Allmand® has a policy of continuous product improvement and reserves the right to modify its specifications at any time and without prior notice. See operator’s manual for complete warranty details.

Options

Camlocks

Interchangeable electrical connectors that can be used in either single or three phase modes

Single Camlocks



Arctic Package

Battery heater pad - 50W 120V battery heater pad

Block Heater - Thermosiphon 1,000W 120V with thermostat

Battery Charger



Battery Charger

5A 120V battery charger with 3 stage charge cycle



Emergency Engine Air Shut-off Valve

Hitch Coupler Options:

2" Ball

2" Bulldog

2-5/6" Ball

2-5/16" Bulldog



Telematics Package (Customer Supplied - consult factory for lead times)



Lockable Battery Disconnect



Skid Mounts
